Description
Whats Included
1x Platinum HD Intercom in Black
1x Platinum 2MP HD Metal Surface Mount Front Door Unit with Built In Access Controller and RFID Reader
2x RFID Tokens
2x Power Supplies (1 for Monitor, 1 for Front Door)
1x Installation Screws, Bracket
1x Instructions
Overview
The Platinum video intercom is a cost-effective premium door entry solution providing HD colour resolution and modern monitor design with controls. It features internal communication, recording and monitoring of front door.
The metal IP65 rated 2MP door camera offers superior night vision due to the Crystal IR filters that enhance color during the day and improve brightness at night. It offers a remarkable 150 degree wide viewing angles both vertically and horizontally to help identify and clearly see who is at the front door. The built in keypad allows you to open the gate with your very own personal password using the built in keypad or with an RFID card reader which allows you to scan registered cards/tags for quick, secure access. No more worrying about misplaced keys or lockouts!
The Platinum intercom is the perfect 4 wire system to all modern homes for security and lifestyle.
HD Monitor Features
- 7 inch 1024×880 HD, hands-free video intercom
- Supports 2 Outdoor stations, 6 indoor monitors
- Supports Electronic and Magnetic Lock
- Works up to 50 meters
- Doorbell volume adjustable
- Contrast & Brightness adjustable
- Hand free clear microphone for communication
- Internal Intercommunication between monitors
Front Door Unit Features
- 2MP HD 1080p Wide Angle 150 Degrees CCD Camera
- Backlight compensation with Infrared Nightvision Camera
- RFID Card Reader (Unlock the Latch with Token/Card)
- Personal password/ID card unlocking function with Keypad
- Comprehensive IP65 Waterproofing
- Metal Alloy Rain Cover
- Luminous buttons
- Name Plate
- Anti-vandal aluminium alloy housing with Nano-glass shield for camera
- Supports 2 door entry
- Includes 2 RFID Tokens
- Includes 2x Power Supplies (1 for Monitor, 1 for Front Door)
Platinum HD intercom combines innovative features with precision engineering with some of the best features;
7” LCD HD MONITOR
Crystal clear 1024×880 HD display with screen and easy to follow GUI menu system.
EXPANDABLE SYSTEM
The monitor can support 6 monitors and 2x front door stations. All the monitors can see, hear, speak to the outdoor camera and unlock the door. Electronic locks can be added to give you more comprehensive protection for your home.
INTERCOMMUNICATION & CALL TRANSFER
When someone presses the doorbell, all the monitors will ring, you can answer and unlock the door with each monitor. All the monitors support call transfer or internal talk between indoor monitors.
WEATHER RESISTANT DOOR CAMERA
Front door housing made from an Anti-oxidation aluminium alloy panel that provides a comprehensive IP65 rating making it rainproof, dustproof and even anti-vandal proof.
KEYPAD AND RFID FOR CONVEICNCE
Simply enter your code on the front door keypad in order to open the gate or unlock the front gate. There are tokens included if you wish to touch or swipe through giving you convenience and added security
SUPERIOR IR NIGHTVISION WITH 2MP (1080P) WIDE ANGLE CAMERA
A 2MP (FULL HD) resolution wide angle camera (150°) comes equipped with the front door unit. It is built with IR CUT and IR LEDS for better night vision. There are two crystal IR filters, one dedicated to color correction during the day while the other is used for enhancing the brightness at night.
4 WIRE SYSTEM
Easy to install and reliable 4 wire system. CAT5e up to 50m.
DOOR RELEASE FUNCTION
Flexible door release options. 12VDC output, N/O or N/C contacts.
CCTV CAMERA AND SENSOR CONNECTION
Connect max 2 CCTV cameras which can trigger recording if MicroSD card is fitted.* CCTV cameras must be AHD or CVBS.
1 YEAR WARRANTY
MONITOR SPECIFICATIONS
Color: Black
Installation: Surface
Resolution: 1024(H)*680(V)
Answering Mode: Hands-free
Application: Indoor
Installation: Surface Mount
Product Material: High quality ABS
Operating Mode: Touch Screen Press
Input power: 12V DC
Power Consumption: 10mA(standby), 250mA(maximum)
Operating Temperature: -10℃~55℃
Transmission Mode: digital transmission
Multiple Monitor Support: Yes, up to 6 monitors can be added per system
Volume Adjustable: Yes
Monitor Dimensions: 220×135×23mm
FRONT DOOR SPECIFICATIONS
Color: Silver
Special Features: NIGHT VISION, Waterproof / Weatherproof
View Angle: 150°
IP Rating: IP65
Product Material: Aluminium alloy
Transmission Mode: Digital Transmission
Power Supply: 15-18VDC
Power Consumption: 100mA, 200mA(maximum)
Operating Temperature: -20℃~60℃
Installation Method: Surface mounted
Resolution: HD 1080P Camera
Wiring: Minimum 4 wires to 6 wires.(CAT5, CAT6, 4 Core and 6 Core Security Cable)
Cable Running Distance: Up to 50m
Multiple Front Door Support: Yes, up to 2
Dimensions：180x68x45mm
Installation size：180x78x55mm
For Latch, you will need 12V or 24V DC
